Dell PowerEdge R760 Rack Server - Options Available

PowerEdge R760 Rack Server Overview

The Dell PowerEdge R760 is the flagship 2U dual-socket rack server powered by 4th and 5th Generation Intel Xeon Scalable processors with up to 120 cores total. Designed as a versatile workhorse for mixed enterprise workloads, the R760 delivers exceptional performance for databases, virtualization, VDI, and business-critical applications while providing extensive storage capacity with support for up to 24 drive bays.

Performance & Scalability

Built on Intel's latest Xeon Scalable platform, the R760 supports dual 5th Gen Intel Xeon processors with up to 60 cores per socket (120 cores total), delivering outstanding parallel processing capabilities. With support for DDR5 memory at speeds up to 5600MT/s across 32 DIMM slots (up to 2TB maximum), the R760 provides the memory bandwidth and capacity necessary for the most demanding enterprise applications.

Advanced thermal management includes SmartFlow air cooling with optimized airflow geometry or optional Direct Liquid Cooling (DLC) for sustained high-performance operation under continuous load. PCIe Gen 5 expansion delivers double the I/O bandwidth for high-speed storage, networking, and GPU acceleration.

Storage Flexibility

The R760 offers exceptional storage flexibility for data-intensive workloads:

• Up to 24 x 2.5" drives (NVMe/SAS/SATA) for maximum density
• Alternatively, up to 12 x 3.5" drives for high-capacity configurations
• Mixed drive configurations combining NVMe for hot data and SAS/SATA for capacity
• PERC 12 RAID controllers with SAS4 24Gbps and hardware acceleration
• BOSS-N1 Boot Optimized Storage with dual M.2 NVMe SSDs
• PCIe Gen 5 NVMe slots for maximum storage performance

Management & Security

Every PowerEdge R760 includes iDRAC9 with Redfish API for modern automation. Enterprise security features include Intel SGX, Intel TXT, TPM 2.0, and silicon root of trust. Cryptographically signed firmware, secure boot, and system lockdown capabilities protect against sophisticated attacks.

Integration with OpenManage Enterprise provides centralized lifecycle management, automated firmware updates, compliance monitoring, and AI-assisted optimization across your infrastructure.

PCIe & GPU Expansion

The R760 provides extensive expansion capabilities:

• Up to 7 x PCIe Gen 5 slots (various configurations)
• Support for up to 4 single-wide GPUs or 2 double-wide GPUs
• 1 x OCP 3.0 slot for integrated networking
• GPU support for AI/ML, VDI, and compute acceleration

Ideal Workloads

• Enterprise database servers (Oracle, SQL Server, SAP HANA)
• Large-scale virtualization (150+ VMs per server)
• Virtual desktop infrastructure (VDI) with GPU acceleration
• Mixed enterprise workloads and application consolidation
• Business intelligence and data warehousing
• ERP and CRM platforms (SAP, Oracle, Microsoft Dynamics)
• High-transaction OLTP systems
• Software-defined storage controllers
• AI/ML model training and inferencing
• Media processing and transcoding

Custom Build-to-Order Configuration

Each PowerEdge R760 is professionally configured with Intel Xeon processors optimized for your workload. Our specialists will design your system with the optimal combination of core count, memory, storage, and cooling at no additional charge.

Optional Services (Additional Fees Apply):

• Windows Server Installation: Microsoft Windows Server can be pre-installed (licensing and installation fees apply)
• Dell ProSupport Warranty: Extended warranty packages available

Expert Configuration: Contact our enterprise server team at 020 3488 4346 or admin@mainnet.uk to discuss your requirements.

*Example configurations. Contact 020 3488 4346 or admin@mainnet.uk to confirm availability and build your custom spec.*
