PowerEdge R760xa Rack Server Overview

The Dell PowerEdge R760xa is a purpose-built 2U dual-socket server optimized for AI training, machine learning inferencing, and GPU-accelerated workloads. Powered by 5th Generation Intel Xeon Scalable processors and supporting up to 12 single-wide or 4 double-wide GPU accelerators, the R760xa delivers exceptional performance for compute-intensive AI/ML applications, deep learning, and high-performance computing requiring massive parallel GPU processing.

Performance & AI Acceleration

Built on Intel's latest platform, the R760xa supports dual 5th Gen Intel Xeon Scalable processors with up to 60 cores per socket (120 cores total), providing the CPU performance necessary for data preprocessing, model training orchestration, and inference serving. With support for DDR5 memory at speeds up to 5600MT/s across 32 DIMM slots (up to 2TB maximum), the R760xa ensures sufficient memory bandwidth for large datasets and model parameters.

The R760xa's defining feature is its exceptional GPU acceleration capability, supporting up to 12 single-width GPUs (75W TDP) or 4 double-width GPUs (up to 350W TDP each). This flexibility enables configurations ranging from high-density AI inferencing with multiple NVIDIA A2 GPUs to extreme-performance AI training with NVIDIA H100 or A100 accelerators.

Storage & Expansion

Configure your R760xa with high-performance storage for AI datasets:

• Up to 8 x 2.5" NVMe drives for maximum I/O performance
• Support for high-capacity SAS/SATA configurations
• PERC 12 RAID controllers with NVMe support and hardware acceleration
• PCIe Gen 5 slots for additional high-speed networking and storage expansion
• OCP 3.0 slot for integrated 100GbE/200GbE networking
• BOSS-N1 Boot Optimized Storage with dual M.2 NVMe for dedicated OS boot

Management & Security

Every PowerEdge R760xa includes iDRAC9 with GPU monitoring and management capabilities, enabling real-time tracking of GPU utilization, temperature, and power consumption. Advanced SmartCooling technology optimizes fan speeds based on GPU thermal load, reducing acoustic noise while maintaining optimal operating temperatures.

Security features include UEFI Secure Boot, TPM 2.0, silicon root of trust, and support for confidential computing with Intel TDX (Trust Domain Extensions) for protecting AI models and sensitive data during processing.

GPU & PCIe Expansion

The R760xa provides maximum GPU acceleration flexibility:

• Up to 12 single-width GPUs (75W each): NVIDIA A2, T4
• Up to 4 double-width GPUs (up to 350W each): NVIDIA A100, H100, L40S
• Mixed GPU configurations supported for hybrid workloads
• PCIe Gen 5 x16 connectivity to each GPU for maximum bandwidth
• Additional PCIe Gen 5 slots for high-speed networking and storage

Ideal Workloads

• AI training and deep learning model development
• Large language model (LLM) training and fine-tuning
• Computer vision and image recognition
• Natural language processing (NLP)
• Real-time AI inferencing at scale
• Generative AI and diffusion models
• High-performance computing (HPC) simulation
• Video transcoding and rendering farms
• Financial modeling and risk analysis
• Scientific research and computational analysis

Custom Build-to-Order Configuration

Each PowerEdge R760xa is professionally configured with Intel Xeon processors and GPUs optimized for AI/ML workloads. Our specialists will design your system with the optimal combination of core count, memory, GPU accelerators, and cooling at no additional charge.

Optional Services (Additional Fees Apply):

• Windows Server Installation: Microsoft Windows Server can be pre-installed (licensing and installation fees apply)
• Dell ProSupport Warranty: Extended warranty packages available

Expert Configuration: Contact our enterprise server team at 020 3488 4346 or admin@mainnet.uk to discuss your requirements.

*Example configurations. Contact 020 3488 4346 or admin@mainnet.uk to confirm availability and build your custom spec.*
