Dell PowerEdge R860 Rack Server - Options Available
Key Features
- Scalable processors with up to 60 cores per socket (240 cores total)
- Up to 16TB DDR5 memory across 64
- DIMM slots at speeds up to 5600MT/s for massive in-memory workloads
- Up to 24 hot-plug drive bays supporting
- SAS/SATA/NVMe in flexible configurations
- Gen 5 expansion slots for high-bandwidth networking and accelerators
- Harness the power of four 5th Gen Intel Xeon Scalable processors delivering up to 240 cores total
- Support up to 16TB of DDR5 memory across 64 RDIMM slots
- Configure with up to 24 x 2.5" hot-plug drives in mixed NVMe/SAS/SATA configurations
- Compact 2U form factor for impressive compute density
- Ideal for SAP HANA, in-memory databases, and mission-critical workloads
Dell PowerEdge R860 - Quad-Socket 2U Server
The Dell PowerEdge R860 delivers exceptional computing power in a space-efficient 2U design. With support for up to four 5th Generation Intel Xeon Scalable processors delivering 240 cores total, and up to 16TB of DDR5 memory, the R860 excels at large-scale in-memory databases, real-time analytics, SAP HANA deployments, and intensive business intelligence workloads.
Technical Specifications
- Processors: Four 5th Gen Intel Xeon Scalable (up to 60 cores each, 240 cores total)
- Memory: Up to 16TB DDR5 5600MT/s (64 RDIMM slots, 16 per processor)
- Storage: Up to 24 x 2.5" hot-plug drives (NVMe/SAS/SATA mixed configurations)
- RAID: PERC 12 controllers with hardware acceleration and SAS4 support
- Networking: OCP 3.0 plus dual 1GbE LOM, support for 100GbE/200GbE adapters
- PCIe: 8 x Gen 5 slots for maximum expansion capability
- Management: iDRAC9 Enterprise with AI-assisted optimization
- Form Factor: 2U rack-mount
Build-to-Order Configurations
SAP HANA / In-Memory Database
- Processors Four Xeon Platinum 8592+ (64 cores each, 256 threads total)
- Memory 12TB DDR5 5600MT/s
- Storage 8 x 3.84TB NVMe SSDs (RAID 10)
- Network Dual 100GbE networking
- Management iDRAC9 Enterprise
Real-Time Analytics Platform
- Processors Four Xeon Gold 6548Y+ (32 cores each)
- Memory 8TB DDR5
- Storage 16 x 1.92TB NVMe SSDs
- Network Dual 25GbE networking
- Management iDRAC9 Enterprise
Mission-Critical Virtualization
- Processors Four Xeon Platinum 8571N (52 cores each)
- Memory 10TB DDR5
- Storage 12 x 7.68TB NVMe SSDs
- Network Dual 25GbE + 10GbE
- Management iDRAC9 Enterprise
Ideal Workloads
- SAP HANA and S/4HANA deployments
- Oracle Database in-memory workloads
- Microsoft SQL Server In-Memory OLTP
- Real-time business intelligence and analytics
- Mission-critical virtualization (VMware vSphere, Microsoft Hyper-V)
- High-performance computing clusters
Custom Build-to-Order Configuration
Each PowerEdge R860 is professionally configured and tested to the highest enterprise standards with extensive burn-in testing and validation at no additional charge. Our specialists will design your system with the optimal combination of processors, memory, storage, and networking.
Optional Services (Additional Fees Apply):
- Windows Server Installation: Microsoft Windows Server can be pre-installed (licensing and installation fees apply)
- Dell ProSupport Warranty: Extended warranty packages available
Expert Configuration: Contact our enterprise server team at 020 3488 4346 or admin@mainnet.uk to discuss your requirements.
*Example configurations. Contact 020 3488 4346 or admin@mainnet.uk to confirm availability and build your custom spec.*
